BennesecurTM

Raised dump body security system

Bennesecur Raised dump body security system

BennesecurTM module from Zone Technologies

  • The Zone Technologies Bennesecur module with its own security system and check body.
  • The system considers the speed of the vehicle via the OBD2 connector of the vehicle.
  • In addition, the system control’s the light and horns provided by the new regulations of the SAAQ.

SPECIFICATIONS

INTEGRATED FUNCTIONS

ELECTRICAL SPECIFICATIONS (BENNESECURTM)

Operating voltage: 10 to 16Vdc
Operating temperature: -40oC to 75oC (-40oF to 167oF)
Current draw: (With 12Vdc input)
  Standby mode, no ignition: 4mA
  Monitoring mode (no load): 140mA (Max)
Available outputs: 12V, 1A (2)
Available inputs: 12V, 10mA (4)
